型號參數(shù)項目

適用帶寬
mm

額定吊高
h/mm

磁場強度
≈mT

勵磁功率
Kw

風(fēng)機功率
Kw

驅(qū)動電機功率Kw

外型尺寸 mm

適用帶速
≤m/s

整機重量
Kg

L

W

H

RCDC-T-6.5

T1

650

200

90

3.0

0.37

2.2

1050

1100

820

4.5

1530

T2

120

5.0

0.75

2.2

1090

1100

820

1680

T3

150

8.0

1.1

2.2

1090

1100

820

1750

RCDC-T-8

T1

800

250

90

5.0

0.37

2.2

1180

1260

860

4.5

2100

T2

120

9.0

0.75

2.2

1180

1260

860

2350

T3

150

13.0

1.1

3.0

1180

1260

860

2480

RCDC-T-10

T1

1000

300

90

7.5

0.75

3.0

1380

1480

1020

4.5

2650

T2

120

12.5

1.1

3.0

1380

1480

1020

3380

T3

150

16.5

1.5

4.0

1380

1480

1020

3950

RCDC-T-12

T1

1200

350

90

10.0

1.5

4.0

1600

1620

940

4.5

4150

T2

120

14.0

1.5

4.0

1600

1620

1000

4650

T3

150

21.0

2.2

5.5

1600

1620

1040

5740

RCDC-T-14

T1

1400

400

90

14.0

1.5

4.0

1780

1860

1070

4.5

5500

T2

120

18.0

0.75×2

5.5

1780

1860

1070

7250

T3

150

26.0

0.75×2

5.5

1780

1860

1070

8160

RCDC-T-16

T1

1600

450

90

15.0

1.5

5.5

1980

2060

1150

4.5

6900

T2

120

32.0

1.1×2

5.5

1980

2060

1150

8670

T3

150

32.0

1.5×2

7.5

1980

2060

1150

10270

RCDC-T-18

T1

1800

500

90

19.0

1.1×2

7.5

2050

2300

1245

4.5

9070

T2

120

28.0

1.5×2

7.5

2050

2300

1245

13150

T3

150

38.0

2.2×2

11.0

2050

2300

1245

15120

RCDC-T-20

T1

2000

550

90

24.0

1.5×2

7.5

2660

2500

1450

4.5

13400

T2

120

32.5

2.2×2

11.0

2660

2500

1450

16500

T3

150

245.0

2.2×2

11.0

2660

2500

1450

19830

RCDC-T-22

T1

2200

600

90

28.0

1.5×2

11.0

2410

2700

1600

4.5

16900

T2

120

36.0

2.2×2

11.0

2410

2700

1600

20830

T3

150

52.0

3.0×2

15.0

2410

2700

1600

24430

RCDC-T-24

T1

2400

650

90

32.0

2.2×2

15.0

22610

2900

1700

4.5

20650

T2

120

43.0

2.2×2

15.0

2610

2900

1750

25820

T3

150

62.0

3.0×2

15.0

2610

2900

1800

30180
